1. The maximum effective rolling width is 1300mm
2. The adhesive amount can be adjusted from 30-150g/M2;
3. The thickness of the material board can be 5-30mm;
4. Speed ≥ 30m/min, controlled by variable frequency motor
5. The middle rolling part does not leak glue; No glue overflow on both sides
6. The feeding adopts silicone belt conveyor
7. The width of the glue groove on the glue roller drum can be adjusted from 300-1300mm. If the width of the VIP board is 600mm, the glue groove limit block can be adjusted to limit the glue width to 580mm, leaving 10mm on one side without glue
8. Automatic adjustment and control of the glue level, using sensors to sense temperature feedback to the temperature controller and then outputting signals to the sol machine, achieving automatic control of the glue level
9. The maximum temperature for use can reach around 220 ° C
10. Dimensions: length 2620 * 2160 * 1400mm, weight approximately 450kg
11. Power of about 6KW (excluding hot melt adhesive machine)
